ZyXEL GS1008HP 8-Port GbE Unmanaged PoE Switch
Empower your connected devices

ZyXEL Products
ZyXEL Products
GS1008HP - 8 Port Gigabit PoE+ Unmanaged Switch (60W Budget)
#GS1008HP
List Price: $94.99
Our Price: $69.99

Click here to jump to more pricing!

Overview:

The Zyxel GS1005HP/GS1008HP GbE Unmanaged PoE Switch is equipped with 5 or 8 Gigabit Ethernet ports, 4 of which are PoE ports that can deliver up to 60 w of total PoE budget. The GS1005HP/1008HP can easily connect with PoE ready devices to your network with plug-and-play design and provides power-saving benefits without compromising performance. The GS1005HP/1008HP fills a long-standing hole in the market for unmanaged PoE switches that feature the 802.3at standard, have a high power budget and are affordable for SOHOs and small businesses.

  • 60 watts of total output on 4/8 Gigabit PoE+ ports
  • LED indicators for PoE budget management
  • Fast Gigabit connection
  • Advanced energy-savings
  • Fanless, noiseless design

Benefits:

Smart PoE+ 802.3af/802.3at support

The Zyxel GS1005HP/GS1008HP GbE Unmanaged PoE Switch supports the IEEE 802.3at standard, providing a maximum of 30 watts per port (with a max total power budget of 60 watts) to supply power to PoE network devices such as wireless APs, IP cameras, and VoIP phones.

Easy PoE budget management

The Zyxel GS1005HP/GS1008HP boasts a total power budget of 60 w and features a handy LED indicator that shows orange when the 50 w threshold is reached.

Gigabit data transmission

Featuring Gigabit performance, it provides 10 times faster than Fast Ethernet. Delivers up to 2,000 Mbps of dedicated bandwidth per port.

Fanless, noiseless design

Fanless design ensures noiseless operation and greater reliability over time with no moving parts that may fail.

Advanced energy-savings at work

IEEE 802.3az Energy Efficient Ethernet (EEE) function automatically detects network traffic and adjusts power consumption dynamically.

Specifications:

Standard

  • IEEE 802.3 10BASE-T Ethernet
  • IEEE 802.3u 100BASE-TX Fast Ethernet
  • IEEE 802.3ab 1000BASE-T Gigabit Ethernet
  • IEEE 802.3 Nway auto-negotiation
  • IEEE 802.3x full duplex operation and flow control
  • IEEE 802.3az Energy Efficient Ethernet

Performance

  • Data transfer rate (half duplex/full duplex):
    • Ethernet: 10/20 Mbps
    • Fast Ethernet: 100/200 Mbps
    • Gigabit Ethernet: 1000/2000 Mbps
  • MAC address table: 4 K
  • Memory buffer: 192 KB
  • Switching fabric (non-blocking): 16 Gbps

Features

  • Compatible With IEEE 802.3af and 802.at Compliant PDs
  • Auto-MDI/MDIX in all ports
  • EEE802.3x Flow Control
  • IEEE 802.1p QoS
  • Jumbo frame support up to 9 KB

Interface

  • 8 RJ-45 10/100/1000 Mbps Ethernet ports with auto MDI/MDIX support

PoE Ports (RJ45)

  • Standard: 802.3af and 802.3at compliant
  • 8 PoE+ ports, up to 30W per port
  • Total PoE Budget : 60W

LED Indicator

  • PWR: Power
  • PoE MAX:
    • Amber: PoE power output over 50W (total budget 60W)
  • Per port: Link/Activity
    • Amber: 10/100 Mbps
    • Green: 1000 Mbps
  • Per port : PoE+
    • Green: PoE supported

Power Supply

  • AC-to-DC external power adapter
  • Input: 100-240 V AC
  • Output: 55V DC/1.3A
  • Item dimensions (WxDxH): 240 x 105 x 26 mm (9.45"x4.13"1.02")
  • Item weight: 610g ( 1.34 lb.)
  • Packing dimensions (WxDxH): 256 x 132 x 78 mm (10.08"x5.20"x3.07")
  • Packing weight: 1260 g (2.78 lb.)

Operating Environment

  • Temperature: 0°C to 40°C (32°F to 104°F)
  • Humidity: 10% to 90% (Non-condensing)

Storage Environment

  • Temperature: -40°C to 70°C (-40°F to 158°F)
  • Humidity: 10% to 90% (Non-condensing)
  • CE, FCC, BSMI, EAC
  • GbE Unmanaged PoE Switch
  • Power adapter
  • Quick Start Guide

Documentation:

Download the ZyXEL GS1008HP Data Sheet (PDF).
