Zyxel XGS1930-28
The most affordable choice for 10G migration
List Price:
Our Price: $449.99
Overview:
Introducing the new hybrid switch
The Zyxel XGS1930 Smart Managed Switch Series introduces Zyxel NebulaFlex™ that allows you to easily switch between standalone and our license-free Nebula cloud management platform anytime with just a few simple clicks.
The NebulaFlex™ protects your investment on wired technology by offering the flexibility to transition to the cloud in your own time, without worrying about additional ongoing licensing costs.
Prudent spender organizations can take advantage of Nebula to centrally manage and access real-time network information to have effortless control over the XGS1930 Smart Managed switches and other Hybrid and Nebula devices – all under a single intuitive platform without the need to install any software.
- NebulaFlex™ gives you the flexibility to switch between standalone and our license-free Nebula cloud management
- Nebula cloud management allows easy deployment, real-time configurations and effortless access to all your cloud devices anytime
- Handles the increasing highbandwidth applications in your office affordably with four built-in 10G SFP+ uplinks
- Easy management and setup with web-based interface and user-friendly wizard
- Smart fan design offers silent operations in your office
- Check real-time status intuitively by cloud and PoE LED indicators
Benefits:
Still like the standalone style?
For those who still stick on standalone management, the XGS1930 Series allow you to set up each switch via its local user-friendly web interface and wizard without learning the complex command line interface (CLI). The wizard quickly guides you to complete the setup process of the most frequently used functions including initial admin setup, VLAN, QoS and protection functions efficiently. Additionally, the XGS1930 Series is also part of the Zyxel One Network, which means that you can use the complimentary ZON Utility to easily perform repetitive operations during the deployment phases.
What’s the benefit of Cloud central management?
When you’re ready to join our Nebula cloud management solution, simply register your XGS1930 Series via the Nebula Control Center (NCC); the device automatically joins, provisions and begins to give real-time information. The intuitive platform allows your switches to form a group, controlled centrally and gain access to diagnostics tools all under a single platform. The Nebula platform does not limit the number of your switches to be added, giving you an easy-to-use, scalable platform to access anytime, anywhere. What’s more, the Nebula platform offers a mobile app for you to register hundreds of devices quickly on NCC with the built-in QR code scanner as well as to monitor the real-time network status.
Experience whisper-silent operations
The XGS1930 Series includes fanless and built-in smart fan models. The smart fan is designed to automatically adjust speeds based on the device temperature to minimize system acoustic noise, starting at 26.3 dBA max at 25°C ambient with XGS1930-52. You can barely hear the sound while the XGS1930 Series is working. It is ideal for your office environment.
Upgrade wired network at a reasonable price
As SMBs generate more data from daily office applications, Gigabit to the desktop raises the importance of 10G connectivity to the core that ensures network efficiency for continuous business productivity. With Gigabit connectivity plus four 10G uplinks, the XGS1930 Series is an ideal option for those who need basic functions, easier management and a more reasonable price to upgrade their networks.
Powering more devices affordably
The XGS1930 Series PoE switches support 802.3at PoE Plus standards to offer 30-watt per port and a 375-watt high-power budget to meet the needs from power-hungry devices. The default consumption mode allows delivery of only the actual power required by devices connected to the switch for better business ROI. The user-friendly PoE consumption indicator located on the front panel and Web GUI provide real-time power utilization.
Application Diagram:
Standalone Management
Cloud Management
Specifications:
| XGS1930-28 | XGS1930-28HP | XGS1930-52 | XGS1930-52HP | |
|---|---|---|---|---|
| Models | ||||
| Product name | 24-port GbE Smart Managed Switch with 4 SFP+ Uplink | 24-port GbE Smart Managed PoE Switch with 4 SFP+ Uplink | 48-port GbE Smart Managed Switch with 4 SFP+ Uplink | 48-port GbE Smart Managed PoE Switch with 4 SFP+ Uplink |
| Switch class | Smart Managed | Smart Managed | Smart Managed | Smart Managed |
| Port Density | ||||
| Total port count | 28 | 28 | 52 | 52 |
| 100/1000 Mbps | 24 | 24 | 48 | 48 |
| 10 Gigabit SFP+ | 4 | 4 | 4 | 4 |
| PoE | ||||
| PoE ports | - | 24 | - | 48 |
| Total PoE budget (Watts) | - | 375 | - | 375 |
| High power PoE 802.3at | - | Yes | - | Yes |
| Performance | ||||
| Switching capacity (Gbps) | 128 | 128 | 176 | 176 |
| Forwarding rate (Mpps) | 95.2 | 95.2 | 130.9 | 130.9 |
| Packet buffer (byte) | 1.5 M | 1.5 M | 1.5 M | 1.5 M |
| MAC address table | 16 K | 16 K | 16 K | 16 K |
| L3 forwarding table | Max. 512 IPv4 entries; Max. 512 IPv6 entries | Max. 512 IPv4 entries; Max. 512 IPv6 entries | Max. 512 IPv4 entries; Max. 512 IPv6 entries | Max. 512 IPv4 entries; Max. 512 IPv6 entries |
| Routing table | 32 | 32 | 32 | 32 |
| IP interface (IPv4/IPv6) | 32/32 | 32/32 | 32/32 | 32/32 |
| Flash/RAM | 32 MB/512 MB | 32 MB/512 MB | 32 MB/512 MB | 32 MB/512 MB |
| Power | ||||
| Input | 100 to 240 V AC, 50/60 Hz | 100 to 240 V AC, 50/60 Hz | 100 to 240 V AC, 50/60 Hz | 100 to 240 V AC, 50/60 Hz |
| Max. power consumption (watt) | 24.6 | 471 | 55.7 | 498.4 |
| Physical Specifications | ||||
| Item | Dimensions (WxDxH)(mm/in.) 441 x 270 x 44/17.36 x 10.63 x 1.73 Weight (kg/lb.) 3.4/7.5 |
Dimensions (WxDxH)(mm/in.) 441 x 330 x 44/17.36 x 12.99 x 1.73 Weight (kg/lb.) 4.6/10.14 |
Dimensions (WxDxH)(mm/in.) 441 x 270 x 44/17.36 x 10.63 x 1.73 Weight (kg/lb.) 3.7/8.16 |
Dimensions (WxDxH)(mm/in.) 441 x 330 x 44/17.36 x 12.99 x 1.73 Weight (kg/lb.) 5.1/11.24 |
| Included accessories |
|
|||
| Green Feature | ||||
| Fanless | Yes | - | - | - |
| Environmental Specifications | ||||
| Operating | Temperature 0°C to 50°C/32°F to 122°F Humidity 10% to 90% (non-condensing) |
|||
| Storage | Temperature -40°C to 70°C/-40°F to 158°F Humidity 10% to 90% (non-condensing) |
|||
| MTBF (hr) | 1,211,024 | 1,369,432 | 827,093 | 494,960 |
| Heat dissipation (BTU/hr) | 83.886 | 1,606.11 | 189.937 | 1,699.544 |
| Acoustic noise @ 25°C (dBA) | 0 | 28.5 | 26.3 | 28.4 |
Features:
| Item | Features |
|---|---|
| Standard Compliance |
|
| Resilience and Availability |
|
| Traffic Control |
|
| Security |
|
| Quality of Service (QoS) |
|
| Layer 2 Multicast |
|
| Routing |
|
| Manageability |
|
| IPv6 Management |
|
| Device Management |
|
| MIB |
|
| Certifications | Safety
|
| Zyxel One Network | ZON Utility
|
| Limited life-time warranty |
* Cloud management mode supports features. |
Documentation:
Download the Zyxel XGS1930 Series Datasheet (PDF).
