Zyxel SFP-10G-SR
10GBASE-SR SFP+ 850nm 300m DOM Transceiver Module
Sorry, this product is no longer available, please contact us for a replacement.
More Zyxel Transceiver Modules are available here
Overview:
The Cisco® 10GBASE SFP+ modules (Figure 1) give you a wide variety of 10 Gigabit Ethernet connectivity options for data center, enterprise wiring closet, and service provider transport applications.
Benefits:
Cisco SFP+ modules offer the following features and benefits
- Industry’s smallest 10G form factor for greatest density per chassis
- Hot-swappable input/output device that plugs into an Ethernet SFP+ port of a Cisco switch (no need to power down if installing or replacing
- Supports “pay-as-you-populate” model for investment protection and ease of technology migration
- Digital optical monitoring capability for strong diagnostic capabilities
- Optical interoperability with 10GBASE XENPAK, 10GBASE X2, and 10GBASE XFP interfaces on the same link
- Cisco quality Identification (ID) feature enables a Cisco platform to identify whether the module is certified and tested by Cisco
Specifications and Features:
| GbE/FE Transceiver Modules | Gigabit SFP | |||
| SFP-1000T | SFP-10G-SR | SFP-LX-10-D | SFP-BX-1310-10-D | |
| Connector | RJ-45 | LC | LC | LC |
| Wavelength | - | 850 nm | 1310 nm | 1310 nm (TX) 1490 nm (RX) |
| Max Transmission Distance | 100 m | 550 m | 10 km | 10 km |
| Receiver Characteristics | ||||
| Optical receiver sensibility | - | -17 dBm | -20 dBm | -20 dBm |
| Maximum input power | - | -3 dBm | -3 dBm | -3 dBm |
| Operational Ranges | ||||
| Supply voltage | 3.1 -3.45 V | 3.1 -3.5 V | 3.1 -3.5 V | 3.1 -3.5 V |
| Max current | 300 mA | 250 mA | 300 mA | - |
| Physical Specifications | ||||
| Dimensions (WxDxH) (mm/in.) | 13.40 x 56.00 x 12.40/0.53 x 2.20 x 0.49 | |||
| Weight (g/lb.) | 24/0.05 | 24/0.05 | 16/0.04 | 17/0.04 |
| With DDMI Features | - | Yes | Yes | Yes |
| Direct Attached Cable 10G Series | DAC10G | |
| DAC10G-1M | DAC10G-3M | |
| Connector | SFP+ to SFP+ | SFP+ to SFP+ |
| Max Transmission Distance | 1 m | 3 m |
| Operational Ranges | ||
| Supply voltage | 3.13 -3.47 V | 3.13 -3.47 V |
| Max current | < 1.5 W | < 1.5 W |
| Physical Specifications | ||
| Dimensions (WxDxH)(mm/in.) | 14 x 58 x 11/0.55 x 2.30 x 0.43 | |
| Weight (g/lb.) | 85/0.19 | 164/0.36 |
Environmental Specifications
- Operating temperature: 0°C to 70°C (32°F to 158°F)
- Storage temperature: -40°C to 85°C (-40°F to 185°F)
Safety Certification
- Class 1 Laser
- 21 CFR 1040.10 and 1040.11 compliant
- CSA (10 Gigabit XFP, Gigabit SFP and Fast Ethernet SFP-10G-SR)
- TUV
- CE (10 Gigabit SFP+ Series, DAC10G Series)
- FDA (10 Gigabit SFP+ Series)
Supported Switches:
| 7000 Series | 4700 Series | |||
| MS-7206 | XGS4700-48F | XGS-4728F | ||
| DAC10G | DAC10G-1M | - | - | - |
| DAC10G-3M | - | - | - | |
| 10 Gigabit XFP | XFP-SR | Yes | Yes | Yes |
| FTLX1412D3BCL (XFP-LR) | Yes | Yes | Yes | |
| 10 Gigabit SFP+ | SFP10G-SR | - | - | - |
| SFP10G-LR | - | - | - | |
| Gigabit SFP | SFP-1000T | Yes | Yes | Yes |
| SFP-10G-SR | Yes | Yes | Yes | |
| SFP-LX-10-D | Yes | Yes | Yes | |
| SFP-BX1310-10-D | Yes | Yes | Yes | |
| SFP-BX1490-10-D | Yes | Yes | Yes | |
| SFP-LHX1310-40-D | Yes | Yes | Yes | |
| SFP-ZX-80-D | Yes | Yes | Yes | |
| Fast Ethernet SFP | SFP-100FX-2 | - | Yes | - |
| SFP-100TX | - | Yes | - | |
| SFP-100LX-20 | - | Yes | - | |
| SFP-100BX1310-20-D | - | Yes | - | |
| SFP-100BX1550-20-D | - | Yes | - | |
| 4500 Series | 3900 Series | |||
| XGS-4526 | XGS-4528F | XS3900-48F | ||
| DAC10G | DAC10G-1M | - | - | Yes |
| DAC10G-3M | - | - | Yes | |
| 10 Gigabit XFP | XFP-SR | Yes | Yes | - |
| FTLX1412D3BCL (XFP-LR) | Yes | Yes | - | |
| 10 Gigabit SFP+ | SFP10G-SR | - | - | Yes |
| SFP10G-LR | - | - | Yes | |
| Gigabit SFP | SFP-1000T | Yes | Yes | - |
| SFP-10G-SR | Yes | Yes | - | |
| SFP-LX-10-D | Yes | Yes | - | |
| SFP-BX1310-10-D | Yes | Yes | - | |
| SFP-BX1490-10-D | Yes | Yes | - | |
| SFP-LHX1310-40-D | Yes | Yes | - | |
| SFP-ZX-80-D | Yes | Yes | - | |
| Fast Ethernet SFP | SFP-100FX-2 | - | - | - |
| SFP-100TX | - | - | - | |
| SFP-100LX-20 | - | - | - | |
| SFP-100BX1310-20-D | - | - | - | |
| SFP-100BX1550-20-D | - | - | - | |
| 3700 Series | |||||
| GS3700-24 | GS3700-24HP | GS3700-48 | GS3700-48HP | ||
| DAC10G | DAC10G-1M | - | - | - | - |
| DAC10G-3M | - | - | - | - | |
| 10 Gigabit XFP | XFP-SR | - | - | - | - |
| FTLX1412D3BCL (XFP-LR) | - | - | - | - | |
| 10 Gigabit SFP+ | SFP10G-SR | - | - | - | - |
| SFP10G-LR | - | - | - | - | |
| Gigabit SFP | SFP-1000T | Yes | Yes | Yes | Yes |
| SFP-10G-SR | Yes | Yes | Yes | Yes | |
| SFP-LX-10-D | Yes | Yes | Yes | Yes | |
| SFP-BX1310-10-D | Yes | Yes | Yes | Yes | |
| SFP-BX1490-10-D | Yes | Yes | Yes | Yes | |
| SFP-LHX1310-40-D | Yes | Yes | Yes | Yes | |
| SFP-ZX-80-D | Yes | Yes | Yes | Yes | |
| Fast Ethernet SFP | SFP-100FX-2 | - | - | - | - |
| SFP-100TX | - | - | - | - | |
| SFP-100LX-20 | - | - | - | - | |
| SFP-100BX1310-20-D | - | - | - | - | |
| SFP-100BX1550-20-D | - | - | - | - | |
| 3700 Series | ||||||||
| MES-3728 | MGS-3712 | MGS-3712F | XGS3700-24 | XG3700-24HP | XGS3700-48 | XGS3700-48HP | ||
| DAC10G | DAC10G-1M | - | - | - | Yes | Yes | Yes | Yes |
| DAC10G-3M | - | - | - | Yes | Yes | Yes | Yes | |
| 10 Gigabit XFP | XFP-SR | - | - | - | - | - | - | - |
| FTLX1412D3BCL (XFP-LR) | - | - | - | - | - | - | - | |
| 10 Gigabit SFP+ | SFP10G-SR | - | - | - | Yes | Yes | Yes | Yes |
| SFP10G-LR | - | - | - | Yes | Yes | Yes | Yes | |
| Gigabit SFP | SFP-1000T | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| SFP-10G-SR | Yes | Yes | Yes | Yes | Yes | Yes | Yes | |
| SFP-LX-10-D | Yes | Yes | Yes | Yes | Yes | Yes | Yes | |
| SFP-BX1310-10-D | Yes | Yes | Yes | Yes | Yes | Yes | Yes | |
| SFP-BX1490-10-D | Yes | Yes | Yes | Yes | Yes | Yes | Yes | |
| SFP-LHX1310-40-D | Yes | Yes | Yes | Yes | Yes | Yes | Yes | |
| SFP-ZX-80-D | Yes | Yes | Yes | Yes | Yes | Yes | Yes | |
| Fast Ethernet SFP | SFP-100FX-2 | - | - | - | - | - | - | - |
| SFP-100TX | - | - | - | - | - | - | - | |
| SFP-100LX-20 | - | - | - | - | - | - | - | |
| SFP-100BX1310-20-D | - | - | - | - | - | - | - | |
| SFP-100BX1550-20-D | - | - | - | - | - | - | - | |
| 3500 Series | ||||
| ES3500-8PD | ES3500-24 | ES3500-24HP | ||
| DAC10G | DAC10G-1M | - | - | - |
| DAC10G-3M | - | - | - | |
| 10 Gigabit XFP | XFP-SR | - | - | - |
| FTLX1412D3BCL (XFP-LR) | - | - | - | |
| 10 Gigabit SFP+ | SFP10G-SR | - | - | - |
| SFP10G-LR | - | - | - | |
| Gigabit SFP | SFP-1000T | Yes | Yes | Yes |
| SFP-10G-SR | Yes | Yes | Yes | |
| SFP-LX-10-D | Yes | Yes | Yes | |
| SFP-BX1310-10-D | Yes | Yes | Yes | |
| SFP-BX1490-10-D | Yes | Yes | Yes | |
| SFP-LHX1310-40-D | Yes | Yes | Yes | |
| SFP-ZX-80-D | Yes | Yes | Yes | |
| Fast Ethernet SFP | SFP-100FX-2 | Yes | Yes | Yes |
| SFP-100TX | Yes | Yes | Yes | |
| SFP-100LX-20 | Yes | Yes | Yes | |
| SFP-100BX1310-20-D | Yes | Yes | Yes | |
| SFP-100BX1550-20-D | Yes | Yes | Yes | |
| 2200 Series | ||||||
| GS2200-8 | GS2200-8HP | GS2200-24 | GS2200-24P | GS2200-48 | ||
| DAC10G | DAC10G-1M | - | - | - | - | - |
| DAC10G-3M | - | - | - | - | - | |
| 10 Gigabit XFP | XFP-SR | - | - | - | - | - |
| FTLX1412D3BCL (XFP-LR) | - | - | - | - | - | |
| 10 Gigabit SFP+ | SFP10G-SR | - | - | - | - | - |
| SFP10G-LR | - | - | - | - | - | |
| Gigabit SFP | SFP-1000T | Yes | Yes | Yes | Yes | Yes |
| SFP-10G-SR | Yes | Yes | Yes | Yes | Yes | |
| SFP-LX-10-D | Yes | Yes | Yes | Yes | Yes | |
| SFP-BX1310-10-D | Yes | Yes | Yes | Yes | Yes | |
| SFP-BX1490-10-D | Yes | Yes | Yes | Yes | Yes | |
| SFP-LHX1310-40-D | Yes | Yes | Yes | Yes | Yes | |
| SFP-ZX-80-D | Yes | Yes | Yes | Yes | Yes | |
| Fast Ethernet SFP | SFP-100FX-2 | Yes | Yes | - | - | - |
| SFP-100TX | Yes | Yes | - | - | - | |
| SFP-100LX-20 | Yes | Yes | - | - | - | |
| SFP-100BX1310-20-D | Yes | Yes | - | - | - | |
| SFP-100BX1550-20-D | Yes | Yes | - | - | - | |
| 1910 Series | |||||||
| GS1910-24 | GS1910-24HP | GS1910-48 | GS1910-48HP | XGS1910-24 | XGS1910-48 | ||
| DAC10G | DAC10G-1M | - | - | - | - | Yes | Yes |
| DAC10G-3M | - | - | - | - | Yes | Yes | |
| 10 Gigabit XFP | XFP-SR | - | - | - | - | - | - |
| FTLX1412D3BCL (XFP-LR) | - | - | - | - | - | - | |
| 10 Gigabit SFP+ | SFP10G-SR | - | - | - | - | Yes | Yes |
| SFP10G-LR | - | - | - | - | Yes | Yes | |
| Gigabit SFP | SFP-1000T | Yes | Yes | Yes | Yes | Yes | Yes |
| SFP-10G-SR | Yes | Yes | Yes | Yes | Yes | Yes | |
| SFP-LX-10-D | Yes | Yes | Yes | Yes | Yes | Yes | |
| SFP-BX1310-10-D | Yes | Yes | Yes | Yes | Yes | Yes | |
| SFP-BX1490-10-D | Yes | Yes | Yes | Yes | Yes | Yes | |
| SFP-LHX1310-40-D | Yes | Yes | Yes | Yes | Yes | Yes | |
| SFP-ZX-80-D | Yes | Yes | Yes | Yes | Yes | Yes | |
| Fast Ethernet SFP | SFP-100FX-2 | Yes | Yes | Yes | Yes | - | - |
| SFP-100TX | Yes | Yes | Yes | Yes | - | - | |
| SFP-100LX-20 | Yes | Yes | Yes | Yes | - | - | |
| SFP-100BX1310-20-D | Yes | Yes | Yes | Yes | - | - | |
| SFP-100BX1550-20-D | Yes | Yes | Yes | Yes | - | - | |
| 1100 Series | |||
| ES1100-24G | GS1100-24 | ||
| DAC10G | DAC10G-1M | - | - |
| DAC10G-3M | - | - | |
| 10 Gigabit XFP | XFP-SR | - | - |
| FTLX1412D3BCL (XFP-LR) | - | - | |
| 10 Gigabit SFP+ | SFP10G-SR | - | - |
| SFP10G-LR | - | - | |
| Gigabit SFP | SFP-1000T | Yes | Yes |
| SFP-10G-SR | Yes | Yes | |
| SFP-LX-10-D | Yes | Yes | |
| SFP-BX1310-10-D | Yes | Yes | |
| SFP-BX1490-10-D | Yes | Yes | |
| SFP-LHX1310-40-D | Yes | Yes | |
| SFP-ZX-80-D | Yes | Yes | |
| Fast Ethernet SFP | SFP-100FX-2 | Yes | Yes |
| SFP-100TX | Yes | Yes | |
| SFP-100LX-20 | Yes | Yes | |
| SFP-100BX1310-20-D | Yes | Yes | |
| SFP-100BX1550-20-D | Yes | Yes | |
Documentation:
Download the Zyxel SFP-10G-SR Datasheet (PDF).
